Making P-System Slots with the Gannomat Machining Centers
Gannomat Index machining center with P-System aggregate Upload the P-System connector using Gannomat’s integrated software toplace the location of each connector on your workpiece Programs can be edited, saved, and viewed for easy repeatability and qualitycontrol Load components onto machine and clamp down using foot pedal View from inside the Gannomat machine as it mills…
Read More
Closet Solutions with Lamello
L-Shelves with Clamex P-14 Consistency in product quality: Zero edge-banding material on separate components
Read More
Ceiling Beam Assembly with P-System
How It works Lay out center lines for connectors on facias and soffit Set Zeta P2 to “14” for the P-14 connectors Set flip stop to desired angle and use the spacer plate if necessary. *Or use stop square for long point referencing Machine P-System slots Using drill jig, drill 6mm wrench access hole for…
Read More
Dividing Panel Joints From 19mm with Tenso P-14
Would you like to connect dividing panel joints invisibly to one another? The offset installation of the Tenso P-14 allows glued joints from a material thickness of <br />19mm to be realised in almost no time. Use a template with uniform spacing instead of marking repeatedly. Clamp the template on the dividing panel as a…
Read More
Gluing Made Easy Thanks to Tenso P
1. Cut all components. 2. Slide in the connectors. 3. Apply glue. 4. Press in the preload-clip to make it easier to join the components. 5. Assemble the components. 6. Ready-glued carcase without waiting times and without any clamps or adhesive tape.
Read More
Drawer Box Construction with Cabineo and Mozaik Software
Current Mokaik subscribers can navigate to library\hardware\fastener\joint template and choose Cabineo connector-flush cover. Then choose parameters in drawer box. On 3D view of box, ensure all parameters are set correctly for box construction and make adjustments before fabrication. Set the size of drawers with those parameters and input drawer box sizes. Rout or drill the…
Read More
How to Join Waterfall Bevel Joints in Thick Material with No Clamps
Hey everyone, it’s Matt from Matt Moore Designs and we’re here in our most recent kitchen renovation where we just finished the installation process of this bar area. The area consists of a beverage cooler, a stack of drawers, but most eye-catching is this solid 8/4 grain wrapped waterfall countertop. Traditional clamping methods to create…
Read More
Hybrid Zeta P2 + CNC Positioning Pin Method
Precise drilling on a CNC machine, use these drill holes to position the Zeta P2 to cut theP-System grooves. This application is especially ideal if the CNC machine is a nesting machineand or no aggregate is available. This method combines the precision and efficiency of aCNC machine and uses the simple and fast machining of…
Read More
Clamping Miters in Thick Material
Mark the connector position and cut the profile groove with the Zeta P2 For the offset groove: Slide on the stop square and set the position Check the cutting position with the machine to prevent cutting through Place the Zeta P2 with the stop square on the outer face and cut the offset grooves Drill…
Read More
Cabineo Time Study
Increase production by at least 50%
Read More
False Drawer Fronts with Tenso P-14
Set Zeta P2 to the 14mm depth setting for Tenso P-14 connectors on the back side of the drawer face Use stop square to create an outside reference fence Run 14mm deep P-System slots on back of drawer face Insert male Tenso P-14 halves into back side of drawer face Set Zeta P2 to the…
Read More
Slat Wall with P-System
How it works: Determine and mark spacing for Tenso connectors Determine and mark spacing for each slat based on material thickness and reveal Extend marks for reference on top and bottom Using a piece of scrap wood, cut spacers to match your reveal Connect spacers to a straight edge with hot glue near the ends…
Read More
Face Frame Cabinets with P-System
How it works: Lay out connector slot location on the back side of face frames Set the stop square on Zeta P2 to the appropriate height Set the top adjustment knob to the correct setting Cut slots on the face frame Cut corresponding slots on cabinet boxes Install connectors Install pre-load clip Apply glue (when…
Read More
